BIMBA 3/4" PANCAKE AIR PNEUMATIC CYLINDER FO-090.25-M
You are bidding on a Pneumatic Magnetic Sensing Bimba Double Acting Pancake Air Cylinder, Model # FO-090.25-M with 1/4 Inch of stroke, 1 1/16" Bore, and a 1/2" Male rod end piston. Cylinder measures 2" High x 2" Diameter.
Force is .9 x air pressure
Body - 304 Stainless Steel
Heads - Anodized Aluminum Alloy
Piston Rod - Ground and Polished 303 Stainless Steel
Piston Seals - Buna N
Rod Bushing - Oil Impregnated Bronze
Rod Seals - Buna N O-ring
Pressure Rating - 200 PSI Maximum (Air only)
For more information see:
Bimba Manufacturing Company was founded in 1957 when Charles Bimba invented an inexpensive, non-repairable, stainless steel body air cylinder to replace small bore repairable cylinders. The product has since become an industry standard and Bimba remains the leading manufacturer of this type of cylinder.
I will fully guarantee this great cylinder.
Many more sizes available - see my other auctions.
Shipping in the Continental US is $4.90 - I have very competitive rates for our always welcomed International bidders.
Thanks for looking! If you have any question on this item please call us at 1-800-826-3433 (9 - 5pm Eastern).
Pay me securely with your Visa or MasterCard through PayPal!
