UP TO 5 NEW THOMSON 1" PRECISION BALL BUSHING BEARINGS SSU16WW
This is a Fixed Auction for up to 5 New in the Box, Thomson 1" Precision Super Smart Ball Bushing Bearings, No.SSU16WW- NEW COST $50.
PLEASE NOTE -- Each Bid is for ONE Bearing.
Ball Bushing Bearing, Closed, Bore Dia. 1.000 In., Inside Dia. Tolerance -0.0005, Outside Dia. 1.563 In., Retention Hole Dia. (in) 0.14, Retention Hole Location 0.13, Between Grooves (in.) 1.901, Length 2.25 In., Static Load Capacity 1900 Lb., Temp. Range 185 F, Delrin Material, Withstand Temp. (Deg. F) 185, Shaft Dia. (In.) 1.000, For Use With Thomson Shafting

Super Smart Ball Bushing

Designed to maintain diametrical fit when installed in housings that are slightly out-of-round. Provide twice the load-carrying capacity, or 8 times the travel life, of Super Ball Bushing bearings and 6 times the load, or 216 times the travel life, of conventional linear bearings.

Linear Ball Bushing Bearings

Steady state speeds to 10 fps; acceleration to 450 fps2 Max. temp.: 185 F Coefficient of friction as low as 0.001 Self-aligning

Bore Dia. 1.000"

Inside Dia. Tolerance -0.0005

Outside Dia. 1.5630"

Retention Hole Dia. (mm) 0.14

Retention Hole Location 0.13

Between Grooves (mm) 1.901

Length (In.) 2.250

Static Load Capacity (Lb.) 1900

Temp. Range (F) 185

New Cost - $130
Many more sizes available - see my other auctions.
I will fully guarantee these Bearings.
Shipping in the Continental US is $4.90 - I have very competitive rates for International bidders that are always welcome.
Thanks for looking! If you have any question on this item please call us at 1-800-826-3433 (9 - 5pm Eastern).
